A Toyota Owner’s Guide to the Actuator Assembly
Do you have an ABS actuator assembly that needs to be replaced? Or are you simply curious about how an actuator assembly works? You came to the right place. This guide covers everything you need to know about Toyota ABS actuator assemblies.
What is an ABS Actuator?
The ABS actuator assembly is the heart of your car’s ABS system. It’s a hydraulic part that pulses the brakes when the ECU tells it to. The ECU monitors the rotational speed of your wheels. When it senses one of the wheels locking up, it immediately sends a signal to the actuator. The actuator then pulses the brakes from locking up. The ABS actuator can pulse the brakes much faster than a human can.
This article explains what the actuator is and how it works in more detail: What is an ABS Actuator Assembly and Why is it Important?
How Can I Diagnose a Failing ABS Actuator Assembly?
Diagnosing an ABS actuator assembly is an easy process you can do at home as long as you have an ohmmeter and a half hour. It involves getting a reading from all of the terminals on the actuator.
This comprehensive tutorial has all the steps you need: How to Know if Your ABS Actuator Assembly is Failing
How Do I Replace an ABS Actuator Assembly?
If you find that your ABS actuator assembly is bad, you’ll need to replace it as soon as possible. Before starting the project, gather together all the tools and supplies you need. You will also want to get an OEM replacement actuator assembly. To find one, look up your Toyota model in our catalog or see if it’s listed here:
- Part No. 44500-47141: For 2006-2009 Prii
- Part No. 47050-60010: For 1998-2003 Land Cruisers and 4Runners
- Part No. 47050-60081: For 2004-2005 4Runners
- Part No. 47050-60321: For 2011 Land Cruisers
- Part No. 47070-47060: For 2010-2018 Prii and RAV4s
If you’re willing to tackle this project yourself, this tutorial will come in handy: How to Replace a Prius Actuator Assembly
Note: this tutorial is for the Prius. The job will be easier on any other non-hybrid vehicle.
